■ Specifications
►SWPB Alloy Code & Corresponding International Code：
►JF800 Alloy CuPb10Sn10 Chemical Composition ( % )：
►Physical & Mechanical Properties：
►Usage Range：
►Possible Application Industrial:
Mechanical handling and lifting equipment, hydraulic cylinders, agricultural equipment, off highway equipment.
| Product Code | Alloy Code | Alloy Hardness | Corresponding International Code |
| SWPB800 | CuPb10Sn10 | 69-90 HB | DIN-CuPb10Sn, SAE-797, JIS-LBC3, GGB-SY, GLYCO-66, FEDERAL MOGUL-HF2, DAIDO-L10, ACL-F100
|
►JF800 Alloy CuPb10Sn10 Chemical Composition ( % )：
| Cu | Pb | Sn | Zn | P | Fe | Ni | Sb | other |
| rest | 9-11 | 9-11 | ≤ 0.5 | ≤ 0.1 | ≤ 0.7 | ≤ 0.5 | ≤ 0.2 | ≤ 0.5 |
►Physical & Mechanical Properties：
| Items | Value | Unit |
| Maximum Operating Temperature Tmax-greased | 150 | °C |
| Maximum Operating Temperature Tmax-oil lubricated | 250 | °C |
| Minimum Operating Temperature Tmin | -40 | °C |
| Maximum Static Load Psta,max | 300 | N/mm2 |
| Maximum Dynamic Load Pdyn,max | 140 |
N/mm2 |
| Maximum Sliding Speed V-greased | 2.5 | N/mm2 * m/s |
| Maximum PV Factor-greased | 2.8 | N/mm2 * m/s |
| Coefficient of friction f-greased | 0.05-0.12 | |
| Coefficient of friction f-oil lubricated | 0.04-0.12 |
►Usage Range：
| dry | poor |
| oil lubricated | good |
| grease lubricated | very good |
| water lubricated | poor |
| process fluid lubricated | poor |
►Possible Application Industrial:
Mechanical handling and lifting equipment, hydraulic cylinders, agricultural equipment, off highway equipment.
